UWE Digital Media Building, Ashton Bower Campus
The University had a comprehensive BIM requirement integral to their future asset procurement strategy for the campus masterplan. This included detailed Employers Information Requirements & provision of a Common Data Environment for the project. The BIM strategy was aligned to PAS1192-2:2013 principles with COBIE asset information as a key deliverable defined within maintainable asset categories. The Client was intent on managing the building during its lifetime through its Archibus CAFM software updating the asset model with up to date information where it will be used for future projects as buildings are modified over time to suit changing needs.
During the design stages clash detection & virtual design reviews were run within a federated model environment using Navisworks incorporating the various stakeholder models.
The asset data requirement was enhanced in the later stages of the project, following Client developments & this was undertaken during Stage 5 in close collaboration with the contract team. Information was exchanged across the team at frequent intervals passing through validation & verification check processes. As the level of information was increasing in depth towards its final suitability status it was adding to the project information model for ultimate integration into the asset information model at handover. This data was uploaded by the Client to their CAFM database, to which the graphical 3D model was also linked, to supply space data to the system.
The model will also be used to manage the movement of staff, allowing planning of furniture layouts as well as also being used to support academic activities.
We are delighted and proud of our new digital media building designed by Austin-Smith:Lord. The building provides a demanding technical function within a striking and elegant design.
A-S:L have been creative and supportive throughout the design and build and have set a benchmark for our campus redevelopment.
Roger Conlon – Deputy Dean, Faculty of Arts, Creative Industries & Education, University of the West of England
CLIENT: UNIVERSITY OF THE WEST OF ENGLAND
SERVICE: ARCHITECTURE, LANDSCAPE, INTERIORS
CONTRACTOR: WILLMOTT DIXON
LANDSCAPE: AUSTIN-SMITH: LORD
COST CONSULTANT: FAITHFUL & GOULD
2018 LABC BRISTOL EXCELLENCE AWARDS: BEST PUBLIC SERVICE BUILDING & BEST EDUCATIONAL BUILDING
LABC WEST OF ENGLAND REGIONAL AWARD: BEST EDUCATIONAL BUILDING
